A Unique de-balancing box, the ARX De-Balancer will convert stereo Balanced Low Impedance signals to Unbalanced Low Impedance signals, to allow leads to run balanced from A to B and then be de-balanced for connecting to a high impedance/unbalanced input at the other end
This enables you to keep a balanced line all the way up to the input of an unbalanced unit, reducing hum, noise and interference pickup along the way. Transformer Ground isolation provides low-noise operation suitable for any application
The heavy duty all-steel chassis is finished in attractive blue textured powdercoat, with hardwearing epoxy screen printing and a large slip resistant rubber base pad.
The ARX De-Balancer is a totally passive device with no power requirements, making it a truly universal problem solver.
Security features include an optional bracket kit for under-table mounting.
Available in Dual Channel format only
Technical Specifications
Input Impedance 10K Ohms Balanced
Output Impedance 10K Ohms Unbalanced
Input Level (max) +12dB
Frequency Response 20Hz – 20 KHz ± 0.5dB
THD at Max Output 0.2% 30 Hz – 20KHz
Insertion Loss 0.75dB @ 1 KHz (600 Ohm source)
Input Connector
3 pin female XLR, wired Pin 1 Ground, Pin 2 + Hot, Pin 3 – Cold. Chassis Ground connected to XLR Pin 1
Output Connectors Dual stereo RCA connectors
Construction
All-steel powdercoated chassis, fibreglass PCB, ultra low noise audio transformer
